Mass storage devices
Item Component Spare part number
(1) Optical drive
DVD+/-RW Double-Layer SuperMulti drive for non-touch models 720246-001
Blu-ray Disc ROM with SuperMulti DVD±R/RW Double-Layer for non-touch models 720247-001
DVD+/-RW Double-Layer SuperMulti drive for touch models 720248-001
Blu-ray Disc ROM with SuperMulti DVD±R/RW Double-Layer for touch models 720249-001
(2) Hard drive
750-GB 5400RPM SATA RAW 63.5mm (2.5 in) 634250-001
1-TB 5400RPM SATA RAW 63.5mm (2.5 in) 676521-001
500-GB 5400RPM SATA RAW 7mm (2.76 in.) 683802-001
(3) Hard drive (mSATA solid-state drive)
24-GB mSATA solid-state drive (SSD) 720264-001
Screws (not illustrated)
Miscellaneous parts
Component Spare part number
AC adapter:
65-W nPFC 3-wire 4.5-mm AC adapter (non-smart) for use in all countries and regions 710412-001
90-W PFC 3-wire 4.5-mm AC adapter (non-smart) for use in all countries and regions 710413-001
120-W PFC 3-wire Slim 4.5-mm AC adapter for use in all countries and regions 710415-001
Power cord (3-pin, black, 1-M):
For use in North America 490371-001
22 Chapter 3 Illustrated parts catalog
