Spare part
number
Description
710412-001 65-W nPFC 3-wire 4.5-mm AC adapter for use in all countries and regions
710413-001 90-W PFC 3-wire 4.5-mm AC adapter for use in all countries and regions
710415-001 120-W PFC 3-wire Slim 4.5-mm AC adapter for use in all countries and regions
710417-001 6-cell, 62WHr 32.8AH Li-ion battery
710418-001 Mediatek MT7630E 802.11 b/g/n 1×1 Wi-Fi and Bluetooth 4.0 combo adapter
711903-001 Intel® Core™ i5-3230M (2.6GHz), 1600MHz (3MB L3, Dual 35W) processor
713163-001 Intel® Core™ i3-3130M (2.6GHz), 1600MHz (3MB L3, Dual 35W) processor
720222-001 WLAN antenna
720223-001 Display enclosure
720225-001 Base enclosure for non-touch models
720226-001 Base enclosure for touch models
720227-001 Display bezel
720229-001 Webcamera/microphone cable
720230-001 TouchPad assembly for touch models
720231-001 Heat sink for models equipped with an Intel HM87 Express chipset and internal graphics (includes
processor and replacement thermal material)
720232-001 Heat sink for models with an Intel HM87 Express chipset, switchable discrete graphics, and an Nvidia
N14P-GV2 (GeForce 740M) graphics card (includes processor and replacement thermal material)
720233-001 For units with Intel HM87 Express chipset, switchable discrete graphics and Nvidia N14P-GT
(GeForce 750M) graphics card (includes processor and replacement thermal material)
720234-001 Heat sink for models equipped with an Intel HM77 Express chipset and switchable discrete graphics
(includes processor and replacement thermal material)
720235-001 Fan
720236-001 Fingerprint reader
720237-001 Hardware kit
720238-001 Display hinges with brackets
720240-001 Power connector for models with switchable discrete graphics
720241-001 Power connector for models with internal graphics
720242-001 Backlit keyboard for non-touch models in black finish for use in the United States (includes keyboard
cable)
720244-001 Backlit keyboard for non-touch models for use in the United States (includes keyboard cable)
720244-031 Backlit keyboard for non-touch models for use in the United Kingdom (includes keyboard cable)
720244-041 Backlit keyboard for non-touch models for use in Germany (includes keyboard cable)
720244-051 Backlit keyboard for non-touch models for use in France (includes keyboard cable)
720244-061 Backlit keyboard for non-touch models for use in Italy (includes keyboard cable)
720244-071 Backlit keyboard for non-touch models for use in Latin America (includes keyboard cable)
24 Chapter 3 Illustrated parts catalog
