Remove the WLAN module:
1. Disconnect the #1 and #2 WLAN antenna cables from the WLAN module (1).
NOTE: The #1 WLAN antenna cable is connected to the WLAN module #1 main terminal. The
#2 WLAN antenna cable is connected to the WLAN module #2 auxiliary terminal.
2. Remove the Phillips PM screws (2) that secure the WLAN module to the system board. (The
WLAN module tilts up.)
Component replacement procedures 39
