HP FlexFabric 5700 series Configuration Guide

110
Attribute Descri
p
tion
Tx type
Transmitter type of the port:
• 10GBASE-CX4.
• 10GBASE-ER 1550nm laser.
• 10GBASE-EW 1550nm laser.
• 10GBASE-LR 1310nm laser.
• 10GBASE-LW 1310nm laser.
• 10GBASE-LX4 WWDM 1300nm laser.
• 10GBASE-SR 850nm laser.
• 10GBASE-SW 850nm laser.
• Electrical-EL.
• Long wave laser cost reduced-LC(1310nm).
• Long wave laser-LL(1550nm).
• Short wave laser-SN(850nm).
Module type
Transceiver module type of the port:
• GBIC with serial ID.
• GBIC without serial ID.
• GLM.
• QSFP.
• SFP-DWDM.
• SFP with serial ID.
• SFP without serial ID.
• X2-DWDM.
• X2 Medium.
• X2 short.
• X2 Tall.
• XENPAK.
• XFP.
• XPAX Medium.
• XPAX short.
• XPAX Tall.
Port number Port index.
Attached port WWNs
WWNs of connected ports.
If the nodes are registered through an NPV switch, there might be
multiple connected ports.
Port state
Current port status:
• Online—The port link is connected.
• Offline—The port link is not connected.

HP FlexFabric 5700 series Specifications

General

Layer Support	L2/L3
Routing Protocol	OSPF, BGP, RIP, IS-IS, Static Routing
Remote Management Protocol	SNMP, CLI, Web
Features	VXLAN
Compliant Standards	IEEE 802.1D, 802.1Q, 802.1w, 802.1s, 802.3ad
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
VLANs	4K
