26
Figure 31 Removing the DC power cord
(1) Press the tabs on the power cord connector with your thumb and
forefinger
(2) Pull the power cord connector out
Figure 32 Removing the power supply
(1) Pivot the latch to the right with your thumb (2) Pull the power supply out
Connecting the power cord
WARNING!
Provide a circuit breaker for each power input. When you connect a power cord, make sure the
circuit breaker is switched off.
