Appendix C Ports and LEDs
Ports
Console port
The switch has two console ports: serial console port and Mini USB console port.
Table 14 Console port specifications
Item Console port Mini USB console port
Connector type RJ-45 USB mini-Type B
Compliant
standard
EIA/TIA-232 USB 2.0
Transmission
baud rate
9600 bps (default) to 115200 bps
Services
• Provides connection to an ASCII
terminal.
• Provides connection to the serial port of
a local or remote (through a pair of
modems) PC running terminal
emulation program.
• Provides connection to an ASCII
terminal.
• Provides connection to the USB
port of a local PC running terminal
emulation program.
Management Ethernet port
The switch has one management Ethernet port. You can connect this port to a PC or management
station for loading and debugging software or remote management.
Table 15 Management Ethernet port specifications
Item Specification
Connector type RJ-45
Connector quantity 1
Port transmission rate 10/100/1000 Mbps, half/full duplex
Transmission medium and max
transmission distance
100 m (328.08 ft) over category-5 twisted pair cable
Functions and services Switch software and Boot ROM upgrade, network management
USB port
The switch has one OHC-compliant USB2.0 port that can upload and download data at a rate up to
480 Mbps. You can use this USB port to access the file system on the Flash of the switch, for
example, to upload or download application and configuration files.
