60
Table 23 System status LED description
LED mark Status Description
SYS
Steady green The switch is operating correctly.
Flashing green The switch is performing power-on self test (POST).
Steady red The system has failed to pass POST or has problems such as fan failure.
Flashing red Some ports have failed to pass POST.
Off The switch is powered off or has failed to start up.
SFP+ port LED
Each SFP+ port has a status LED to show port operating status and activities.
Table 24 SFP+ port LED description
LED status Description
Steady green
A transceiver module or cable has been correctly installed. The port has a link and is
operating at 10 Gbps.
Flashing green The port is sending or receiving data at 10 Gbps.
Steady yellow
A transceiver module or cable has been correctly installed. The port has a link and is
operating at 1 Gbps.
Flashing yellow The port is sending or receiving data at 1 Gbps.
Off No transceiver module or cable has been installed or no link is present on the port.
QSFP+ port LED
Each QSFP+ port has a status LED to show port operating status and activities.
Table 25 QSFP+ port LED description
LED status Description
Steady green
A transceiver module or cable has been correctly installed. The port has a link
and is operating at 40 Gbps.
Flashing green The port is sending or receiving data at 40 Gbps.
Steady yellow
A transceiver module or cable has been correctly installed. The port has a link
and is operating at 10 Gbps.
Flashing yellow The port is sending or receiving data at 10 Gbps.
Off
No transceiver module or cable has been installed or no link is present on the
port.
Management Ethernet port LEDs
The HPE 5930-32 QSFP+/HPE 5930-32 QSFP+ TAA/HPE 5930-4Slot/HPE 5930-4Slot TAA
switches provide a LINK LED and an ACT LED for the management Ethernet port.
