Rear panel components
NOTE: Your computer model may look slightly dierent from the illustration in this section.
Item Icon Component Item Icon Component
1 Antenna cover 7 USB 3.1 Gen 2 ports (2)
2 Thumbscrew 8 Optional port
One of the following ports may be used:
DisplayPort, HDMI, VGA, USB Type-C, or
serial port
3 Security cable slot 9 USB 3.1 Gen 1 ports (2)
4 External antenna connector (optional) 10 RJ-45 (network) jack/status lights
5 Padlock loop 11 Power connector
6 Dual-Mode DisplayPort (2)
Serial number location
Each computer has a unique serial number and a product ID number that are located on the exterior of the
computer. Keep these numbers available for use when contacting support for assistance.
2 Chapter 1 Product features
