Hood sensor
The hood sensor is located near the front of the computer.
1. Prepare the computer for disassembly (Preparation for disassembly on page 14).
2. Remove the access panel (Access panel on page 15).
3. Lift the rubber cover from the hood sensor (1).
4. Disconnect the cable from the system board, and then lift the hood sensor out of the computer (2).
To install the hood sensor, reverse the removal procedure.
Hood sensor 17
