HP Nc6400 - Compaq Business Notebook Maintenance And Service Guide

Removal and Replacement Procedures
Maintenance and Service Guide 5–41
✎
The thermal paste and thermal pads should be thoroughly
cleaned from the surfaces of the heat sink 1, processor 2,
Chip1 3, and Chip2 4 each time the heat sink is removed.
Thermal paste and thermal pads are included with all heat sink,
processor, and system board spare part kits.
Thermal Paste and Thermal Pad Locations
Reverse the above procedure to install the heat sink.

HP Nc6400 - Compaq Business Notebook Specifications

General

Operating System	Windows XP Professional
Networking	10/100/1000 Gigabit Ethernet
Processor	Intel Core 2 Duo
RAM	Up to 4GB DDR2
Storage	80 GB HDD
Display	14.1-inch WXGA (1280 x 800)
Graphics	Intel GMA 950
Battery	6-cell Lithium Ion
Chipset	Intel 945GM Express
Optical Drive	DVD+/-RW
Wireless	Intel PRO/Wireless 3945ABG
Ports	3 USB 2.0, VGA, headphone, microphone, RJ-11, RJ-45
Slots	ExpressCard/54
Dimensions	13.1 x 9.3 x 1.2 in
