Removal and Replacement Procedures
Maintenance and Service Guide 5–49
14. Remove the following:
1 and 2 four rubber screw covers
✎
The two rubber screw covers 1 on the top edge of the display
bezel are different from the two rubber screw covers 2 on the
bottom edge of the display bezel.
Both types of rubber screw covers are included in the Display
Rubber Kit, spare part number 418893-001.
3 Four Phillips PM2.5×6.0 screws
Removing the Display Bezel Screws
