5–50 Maintenance and Service Guide
Removal and Replacement Procedures
15. Flex the insides edges of the left and right sides 1 and the
top and bottom sides 2 of the display bezel until the bezel
disengages from the display enclosure.
16. Remove the display bezel 3.
Removing the Display Bezel
Display Assembly Components
Spare Part Number Information
Description
Spare Part
Number
Display bezel 418889-001
Display enclosure 418895-001
