Removal and Replacement Procedures
Maintenance and Service Guide 5–51
17. If it is necessary to replace the display hinges, remove the
Phillips PM2.5×4.0 screw 1 and the Phillips PM2.5×6.0
screw 2 that secure each hinge to the display enclosure.
18. Remove the display hinges 3.
Removing the Display Hinges
Display Assembly Components
Spare Part Number Information
Description
Spare Part
Number
Display Hinge Kit 418902-001
