Removal and Replacement Procedures
Maintenance and Service Guide 5–57
4. Turn the computer right-side up with the front toward you.
5. Disconnect the following cables from the system board:
1 TouchPad cable
2 Fingerprint reader board cable
3 Smart card assembly cable
Disconnecting the Top Cover Cables
