Screw Listing
Maintenance and Service Guide A–3
Phillips PM2.5×13.0 Screw Location
Table A-3
Phillips PM2.5×13.0 Spring-Loaded Screw
Color Qty. Length Thread
Head
Width
Silver 1 13.0 mm 2.5 mm 6.0 mm
Where used:
One screw that secures the hard drive to the computer (screw is captured on the
cover by a C-clip; documented in Section 5.4)
mm
