2-4 Removal and Replacement HP Omnibook 500
Removing the Main Battery
(User-Replaceable)
One or two plug-in modules can be inserted in the module bays in the expansion base. The computer
itself has no module bays.
Required Equipment
•
None.
Removal Procedure
•
Slide the battery’s release latch, then lift the battery out of its compartment.
Figure 2-2. Removing the Main Battery
Reassembly Note
•
Insert the front end of the battery into the battery compartment, then press the back end in until it
clicks into place.
