HP Omnibook 500 Removal and Replacement 2-23
Removing the Top Case
(HP Authorized Service Providers Only)
Required Equipment
•
#0 Phillips screwdriver.
•
Small flat-blade screwdriver.
Removal Procedure
1. Unplug the AC adapter, if present, and remove the battery.
2. Remove these additional assemblies:
•
Hard disk drive (page 2-6).
•
Power button panel (page 2-9).
•
Keyboard (page 2-10).
•
Switchboard PCA (page 2-15).
•
Display assembly (page 2-18).
3. Remove the screws from inside the battery compartment.
4. Remove the six screws from the bottom case.
5. Remove the four screws from the top case.
6. Disconnect the click/scroll button flex cable.
7. Disconnect the audio-off LED cable.
8. Lift the top case off of the computer.
