HP Omnibook 500 Removal and Replacement 2-17
Replacing Small Parts
(User-Replaceable)
The user can replace the following small parts.
Table 2-7. Replacing Small Parts (User-Replaceable)
Part Replacement Procedure
Cover, SDRAM
From the bottom of the computer, remove the screw in the SDRAM module cover,
then remove the cover.
Cover, Trackpoint
Pull the old cover off, and press the new cover into place.
Covers, display hinge
Use a flat-blade screwdriver to carefully pry the covers off of the hinges.
Reassembly Notes:
Insert the tab on the cover into the slot in the top case, and
press the cover into place. Note that the right display hinge cover has a microphone
icon on its front surface.
Covers, display screw
Insert a small flat-blade screwdriver under the screw cover and pry it loose. To
replace, press the adhesive side of the cover firmly into the recess.
Feet, rubber (on
bottom of computer
and expansion base)
Insert a small flat-blade screwdriver under the foot and pry it loose. To replace, firmly
press the adhesive side of the foot into the recess.
Keyboard
See page 2-10.
Tray, hard disk drive
See page 2-6.
