HP OmniBook 6000 Service Manual

HP OmniBook 6000 Product Information 1-13
Internal Design
The motherboard PCA is the central component of the OmniBook’s design. It plays a role in virtually
all system functions. The CPU module and most other subsystems connect to the motherboard.
The following figure shows the connections among the OmniBook’s replaceable electronic modules.
In addition, the table on page 1-14 lists the roles that the replaceable modules play in each of the
OmniBook’s functional subsystems.
Figure 1-5. Replaceable Module Diagram
Motherboard PCA
Heatsink
(fan)
CPU
module
Volume
PCA
Plug-In Module or
Battery
Main Battery
PCMCIA
Socket
PCMCIA
Cards
Hard Disk
Drive
Mini-PCI
Card
Mini-PCI
Panel
Top Case
(speakers, touch pad,
click buttons)
Power Supply
PCA
Display
Interface PCA
SDRAM
Module
Keyboard
(pointing stick)
Display
Assembly
