HP OmniBook 6000 Service Manual

2-14 Removal and Replacement HP OmniBook 6000
Figure 2-10. Removing the Display
Reassembly Notes
• Before installing any screws, make sure the center hinge cover fits over the tab in the bottom case.
Important
• Make sure the DIP switches on the display interface PCA match the settings shown on the
label on the display cable, or you risk damaging the display.
• If you change the DIP switches, you must also reprogram the EEPROM for the new display—
see page 2-26. If the EEPROM is not programmed correctly, the display will not turn on.
Screws,
M2.5×6mm (5)
Screws, M2.5×6mm (2)
Screws, M2.5×6mm (4)
Label with DIP switch
settings
