HP OmniBook 6000 Removal and Replacement 2-13
Removing the Display Assembly
(HP Authorized Service Providers Only)
Required Equipment
• Small Phillips screwdriver.
Removal Procedure
1. Unplug the ac adapter, if present, and remove the battery. Remove the secondary battery if one is
installed.
2. Remove the power button panel (page 2-11).
3. From the back of the computer, remove the two screws near the PS/2 keyboard/mouse port, and the
two near the ac adapter jack.
4. From the bottom of the computer, remove the two screws from the rear corners.
5. Open the display. Remove the screw from the display’s ground wire, and disconnect the main
cable.
6. Remove the screws from the center hinge cover, and from the left and right hinges.
7. Lift the display off of the computer.
To Next Page
