2-18 Removal and Replacement HP OmniBook 6000
Removing the CPU Module
(HP Authorized Service Providers Only)
Table 2-8. CPU/Motherboard Component Compatibility
Pentium III models Celeron models
CPU module F1979-69101 (600/500 MHz)
F1980-69101 (650/500 MHz)
F2072-69102 (700/600 MHz)
F2072-69101 (550 MHz)
PCA, motherboard F2072-60913 F2072-60914
Required Equipment
• Small Phillips screwdriver.
• Small flat-blade screwdriver.
Removal Procedure
1. Unplug the ac adapter, if present, and remove the battery. Remove the secondary battery if one is
installed.
2. Remove these additional assemblies:
• Power button panel (page 2-11).
• Keyboard (page 2-15).
• Heatsink (page 2-17).
3. Turn the lock screw one-half turn counterclockwise to release the CPU module, and remove the
CPU module from the motherboard.
