HP OmniBook 6000 Removal and Replacement 2-9
Removing the Mini-PCI Card
(User-Replaceable)
Certain OmniBook models include a mini-PCI card.
Table 2-6. Mini-PCI Card Replacement Part Numbers
Description Part Number Exchange Part Number
Card, mini-PCI (LAN/modem) F2072-60902
Card, mini-PCI (SW modem) F2072-60903
Caution
Handle the mini-PCI card only by its edges and provide proper grounding, or you might damage the
board by electrostatic discharge.
Required Equipment
• Small Phillips screwdriver.
Removal Procedure
1. Unplug the ac adapter, if present, and remove the battery. Remove the secondary battery if one is
installed.
2. Loosen the screw holding the mini-PCI cover (the cover retains the screw), and remove the cover.
3. Release the latches at the sides of the board, so that the free edge of the board pops up.
4. Detach all the cables from the board.
5. Gently pull the board out of its connector.
Figure 2-8. Removing the Mini-PCI Card
