HP OmniBook 6000 Service Manual

HP OmniBook 6000 Removal and Replacement 2-21
Figure 2-15. Removing the Top Case
Reassembly Notes
• If you need to reinstall the sound/IR panel, make sure the volume control is oriented properly (pins
facing inward). Insert the tabs on the end of the panel into the slots in the bottom case.
• When reinstalling the right corner cover, first insert the tab at the back end of the cover into the
case, then move the plug-in module latch forward and snap the cover over the latch and into place.
Caution
Be careful not to pinch the speaker wires when reinstalling the nearby retaining screws.
Screws,
M2.5x6mm
(
2
)
PCMCIA doors
Screws, M2.5x6mm (3)
Screws, M2.5x4mm (2)
Cover,
right corner
Panel,
sound/IR
Panel,
vent
Cover, left
corner
Screw, M2.5x2mm
Docking doors
Touch pad
flex cable
Screws,
M2.5x6mm
(
3
)
