2-6 Removal and Replacement HP OmniBook 900
Figure 2-3. Removing a RAM Board
Reassembly Notes
• Insert the RAM board into the connector at about a 30° angle until it is fully inserted. Then press
down at both sides until both latches snap closed.
• Fold the keyboard back into place. Slip its front tabs into the slots, then snap the back edge into
place.
• Push the keyboard toward the back as you tighten the two screws. This helps engage the tab at the
back-center of the keyboard.
Removing the Hard Disk Drive
(User-Replaceable)
Exchange Information
When returning a bad hard disk drive to HP, describe the symptoms on a piece of paper and
attach it to the part—do not use tape.
Table 2-5. Hard Disk Drive Replacement Part Numbers
Description Part Number Exchange OmniBook
Part Number 900B 900†
Drive, hard disk (4.3GB, 9.5mm, IBM) * 0950-3409 F1711-69100
•
Drive, hard disk (4.3GB, 8.45mm, Toshiba) 0950-3410 F1386-69102
•
Drive, hard disk (6.0GB, 9.5mm, IBM) * 0950-3710 F1711-69106
•
Drive, hard disk (6.4GB, 9.5mm, IBM) * 0950-3442 F1711-69101
•
Drive, hard disk (12GB, 9.5mm, IBM) * 0950-3711 F1660-69105
•
* These hard drives are the preferred drives at the time of publication. Drives shipped in units are
subject to change without notice. For current information about preferred and approved drives for
these products, see the latest version of service note HDD-01.
† Models called 900† in this manual have no marking in the serial number, whereas models called 900B
have 900 B after the serial number.
Required Equipment
• Small Phillips screwdriver.
Keyboard-screw cover
Screw, M2.5×4mm (2)
RAM board
To Next Page
