HP OmniBook 900 Removal and Replacement 2-9
Replacing Small Parts
(User-Replaceable)
The following small parts are user-replaceable.
Table 2-6. Replacing Small Parts (User-Replaceable)
Part Replacement Procedure
Battery panel
Remove the battery, then twist the upper edge of the panel off the battery.
Bumper, display
(upper)
Insert a small flat-blade screwdriver under the bumper and pry it loose. To replace,
firmly press the adhesive side of the bumper into the recess.
Cap, pointing stick
Pull the cap off the pointing stick.
Cover, display screw
(lower)
Insert a small flat-blade screwdriver under the cover and pry it loose. To replace,
firmly press the adhesive side of the cover into the recess.
Cover, hinge
Put your finger above the F8 key and slide the keyboard-screw cover to the left about
3 mm (1/8 inch)—then lift off the cover. Open the display fully. Push in at the bottom-
front of the cover to unsnap it from the top case.
Cover, keyboard
screw
Put your finger above the F8 key and slide the keyboard-screw cover to the left about
3 mm (1/8 inch)—then lift off the cover.
Door, hard disk
Open the door about 45° and flex the door until one side tab releases.
Foot
Insert a small flat-blade screwdriver under the foot and pry it loose. To replace, firmly
press the adhesive side of the foot into the recess.
