HP OmniBook 900 Service Manual

HP OmniBook 900 Removal and Replacement 2-13
Figure 2-7. Removing the Keyboard
Reassembly Notes
• To connect the flex cables, lay the keyboard upside-down on the front section of the top case.
• Fold the keyboard back into place. Slip its front tabs into the slots, then snap the back edge into
place.
• Push the keyboard toward the back as you tighten the two screws. This helps engage the tab at the
back-center of the keyboard.
Keyboard
Keyboard-screw
cover
Screw, M2.5×4mm
Keyboard flex cable
Pointing stick flex cable
