Description Spare part number
832397-001
Display cable 832764-001
814715-001
Before disassembling the tablet, follow these steps:
1. Turn o the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on, and
then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
NOTE: When replacing the back cover, be sure to remove the POGO connector and cable (see POGO (10-pin)
docking connector cable on page 43) from the defective back cover and installed on the replacement back
cover.
Remove the back cover:
CAUTION: Before turning the display panel assembly upside down, make sure the work surface is clear of
tools, screws, and any other foreign objects. Failure to follow this caution can result in damage to the display
panel assembly.
1. Place the tablet on a at surface, display panel side down, with the power button toward you.
2. Insert a thin, plastic tool between the back cover and the display panel assembly. The rst insertion
point should be just to the left of the microphone openings.
3. Lift the front edge of the back cover (1) until it separates from the display panel assembly.
4. Lift the left and right edges of the back cover (2) until it separates from the display panel assembly.
5. Release the zero insertion force (ZIF) connector (3) to which the POGO connector cable is attached, and
then disconnect the POGO connector cable from the system board.
Back cover 27
