POGO (10-pin) docking connector cable
Description Spare part number
POGO (10-pin) docking connector cable for products not equipped with a hard drive 833623-001
POGO (10-pin) docking connector cable for products equipped with a hard drive 833624-001
Before releasing the POGO-pin (10-pin) docking connector cable, follow these steps:
1. Turn o the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on, and
then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 26), and then remove the following components:
a. Battery (see Battery on page 28)
b. Audio jack board (see Audio board on page 30)
c. Speakers (see Speakers on page 31)
d. Touch board (see Touch board on page 33)
e. System board (see System board on page 34)
f. Wireless antenna (see Wireless antenna on page 37)
g. Power/volume button board (see Power/volume button board on page 38)
h. Webcam module (see Webcam module on page 40)
i. Middle frame (see Middle frame on page 42)
Remove the POGO (10-pin) docking connector board:
1. Release the ZIF connector (1) that secures the POGO (10-pin) docking connector board to the display
panel assembly.
POGO (10-pin) docking connector cable 43
