HP Pavilion x2 Detachable User Manual

1 Product description
Category Description
Product Name HP Pavilion x2 Detachable
HP x2 210 G1 Tablet
Processor Intel Z8300 1.44 GHz quad core processor soldered-on-circuit (SoC)
Panel 10.1-in (1280x800), Antiglare (AG), light-emitting diode (LED), WXGA, TouchScreen display panel
Graphics Internal graphics:
Intel 7th generation graphics and media encode/decode engine 2D/3D graphics
Supports DX11, OpenGL 3.0 (OGL 3.0), OpenCL 1.2 (OCL 1.2), and OpenGLES 2.0 (OGLES 2.0)
Memory On-board; non-accessible
2 GB DDR3L or 4 GB DDR3L
Supports up to 2 GB or 4 GB (select products only) maximum system memory
Mass storage Supports 32- or 64-GB eMMC (v5.0)
Audio and video Stereo speakers (2)
Dual array digital microphones with appropriate beam-forming, echo-cancellation, and noise-
suppression software
Audio codec ALC5642
HD webcam: 1/6-in, F2.4, 1.26-MP max., (1280x720), 720P, 30 fps
Sensor Accelerometer
Ambient Light Sensor
eCompass
Gyroscope
Hall sensor
Thermistor
Wireless networking Integrated wireless options:
Intel 3165NGWG ac, 1x1 Bluetooth 4.0 LE PCIe+USB NGFF 2230 WW (Stone Peak 1)
AzureWave AW-NB177NF Realtek RTL8723BS 802.11 (1x1 b/g/n, Single Band, Bluetooth 4.0) with
single antenna (SDIO+UART)
Supports Miracast
External expansion Integrated microSD Card Reader expandable to 2 TB
Supports SD 3.0
Ports
●
Audio: headphone/microphone combo jack
●
MicroSD Card Reader
●
One USB 2.0 port, one USB 2.0 type C port support charging and data
●
Micro HDMI v1.4a port supporting up to 2048x1024, 1920x1080 @ 60Hz
1

HP Pavilion x2 Detachable Specifications

General

Processor	Intel Atom x5-Z8300
Storage	32GB eMMC
Operating System	Windows 10 Home
Graphics	Intel HD Graphics
Bluetooth	Bluetooth 4.0
RAM	2GB
Display	10.1-inch IPS touchscreen, 1280 x 800
Wireless	802.11 b/g/n
Ports	1 x USB 2.0, 1 x micro HDMI, 1 x headphone/microphone combo
Battery	33 Wh Li-ion polymer
