Page #48 background image
Webcam module
Description Spare part number
Webcam module with microphone (includes cable and double-sided adhesive) 833626-001
Before removing the webcam module, follow these steps:
1. Turn o the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on, and
then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 26), and then remove the following components:
a. Battery (see Battery on page 28)
b. Audio jack board (see Audio board on page 30)
c. Speakers (see Speakers on page 31)
d. Touch board (see Touch board on page 33)
e. System board (see System board on page 34)
f. Wireless antenna (see Wireless antenna on page 37)
g. Power/volume button board (see Power/volume button board on page 38)
Remove the webcam module:
1. Release the ground tape (1) that secures the webcam module to the display panel assembly.
2. Detach the microphones (2) from the display panel assembly. (The webcam module cable is attached to
the display panel assembly with double-sided adhesive.)
3. Remove the broad head screw (3) that secures the webcam module to the display panel assembly.
40 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
