3. Remove 4 screws (3) from the TouchPad bracket, and then lift the bracket(4) to remove it.
4. Lift the TouchPad (5) to remove it.
Reverse this procedure to install the TouchPad.
Hinge cover
Description Spare part number
Hinge cover for products not equipped with a hard drive
In Turbo Silver nish 833629-001
In Blizzard White nish 833630-001
In Sunset Red nish 833631-001
Hinge cover for products equipped with a hard drive
In Turbo Silver nish 833632-001
In Blizzard White nish 833633-001
In Sunset Red nish 833634-001
Before removing the hinge cover, follow these steps:
1. Remove the tablet from the keyboard (see Releasing the tablet from the keyboard base on page 25), and
then remove the following components:
a. Keyboard base (see Keyboard base on page 44).
b. Hard drive (see Hard drive (select products only) on page 46).
Hinge cover 49
