HP Pavilion x2 Detachable User Manual

4. Use a nylon pry tool to open the hinge cover(1) , and then lift the hinge cover(2) to remove it.
Reverse this procedure to install the hinge cover.
POGO connector
Description Spare part number
POGO (10-pin) docking connector board (includes cable) 814723-001
832767-001
Before removing the POGO connector, follow these steps:
1. Remove the tablet from the keyboard (see Releasing the tablet from the keyboard base on page 25), and
then remove the following components:
a. Keyboard base (see Keyboard base on page 44).
b. Hard drive (see Hard drive (select products only) on page 46).
c. Keyboard board (see Keyboard board on page 47).
d. TouchPad (see TouchPad on page 48).
e. Hinge cover (see Hinge cover on page 49).
POGO connector 51

HP Pavilion x2 Detachable Specifications

General

Processor	Intel Atom x5-Z8300
Storage	32GB eMMC
Operating System	Windows 10 Home
Graphics	Intel HD Graphics
Bluetooth	Bluetooth 4.0
RAM	2GB
Display	10.1-inch IPS touchscreen, 1280 x 800
Wireless	802.11 b/g/n
Ports	1 x USB 2.0, 1 x micro HDMI, 1 x headphone/microphone combo
Battery	33 Wh Li-ion polymer
