3. Remove the hard drive connector(1), and then remove the hard drive bracket(2) from the hard drive.
Reverse this procedure to install the hard drive.
Keyboard board
Description Spare part number
Keyboard board for products not equipped with a hard drive 833627-001
833639-001
Keyboard board for products equipped with a hard drive 833628-001
Before removing the keyboard board, follow these steps:
1. Remove the tablet from the keyboard (see Releasing the tablet from the keyboard base on page 25).
2. Remove the tablet from the keyboard (see Releasing the tablet from the keyboard base on page 25), and
then remove the following components:
a. Keyboard base (see Keyboard base on page 44).
b. Hard drive (see Hard drive (select products only) on page 46).
3. Disconnect the TouchPad cable(1), disconnect the keyboard cable (2), and then disconnect the POGO
cable(3).
Keyboard board 47
