HP Pavilion x2 Detachable User Manual

Touch board
Description Spare part number
Touch board (includes cable) 814725-001
Before removing the touch cable, follow these steps:
1. Turn o the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on, and
then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 26).
5. Remove the battery (see Battery on page 28).
Remove the touch cable:
1. Remove the tape (1) covering the ZIF connector.
2. Release the ZIF connector (2) to which the touch cable is attached, and then disconnect the touch board
from the display panel assembly.
3. Remove the touch cable (3).
Touch board 33

HP Pavilion x2 Detachable Specifications

General

Processor	Intel Atom x5-Z8300
Storage	32GB eMMC
Operating System	Windows 10 Home
Graphics	Intel HD Graphics
Bluetooth	Bluetooth 4.0
RAM	2GB
Display	10.1-inch IPS touchscreen, 1280 x 800
Wireless	802.11 b/g/n
Ports	1 x USB 2.0, 1 x micro HDMI, 1 x headphone/microphone combo
Battery	33 Wh Li-ion polymer
