Speakers
Description Spare part number
Speaker Kit (includes left and right speakers and cables) 814735-001
Before removing the speakers, follow these steps:
1. Turn o the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on, and
then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 26).
5. Remove the battery (see Battery on page 28).
Remove the speakers:
1. Disconnect the speaker cable (1) from the system board.
2. Release the ground tape (2) that secures the speaker cable to the display panel assembly.
3. Release the speaker cable from the clips (3) and routing channel built into display panel assembly.
4. Remove the four screws (1) that secure the speakers to the display panel assembly.
Speakers 31
