Note
This section applies only to HP Pavilion 5300 and 5200, HP nx9010, and Compaq Presario 2500
models.
Required Equipment
• #1 Phillips screwdriver.
Removal Procedure
1.
2.
3.
4.
5.
6.
7.
Unplug the AC adapter, if present, and remove the battery.
Remove these additional assemblies:
• Hard disk drive (page 2-9).
• Keyboard cover (page 2-12).
• Keyboard (page 2-16).
• Switchboard PCA (page 2-18).
• Display assembly (page 2-23).
• Top case (page 2-26).
Remove the insulating tape that secures the floppy drive flex cable to the TouchPad bracket on the
top case.
Remove the four M2.5×6.0 mm screws that secure the floppy drive and floppy drive bezel to the
top case.
Remove the floppy drive.
Remove the M2.0×3.0 screw that secures the floppy drive bezel to the floppy drive.
Remove the floppy drive bezel.
2-34 Removal and Replacement Service Manual
