Figure 1-3. Bottom View
HP Pavilion 4300, 4200, and 4100, HP nx9005 and nx9000, and Compaq Presario 2100
2
8. Hard disk drive.
2
9. Battery latch.
3
0. SDRAM door.
31. Reset button.
32. Port replicator connect.*
33. Mini-PCI door (no user parts inside).
* on certain models
1-50 Product Information Service Manual
