Removing the CPU Module
(Authorized Service Providers Only)
Required Equipment
• Small flat-blade screwdriver.
Note
This section applies only to HP Pavilion 4300, 4200, and 4100, HP nx9005 and nx9000,
Compaq Evo Notebook N1050 and N1010, and Compaq Presario 2100 and 1100 models.
Removal Procedure
1.
2.
Unplug the AC adapter, if present, and remove the battery.
Remove these additional assemblies:
• Hard disk drive (page 2-9).
• Keyboard cover (page 2-12).
• Keyboard (page 2-16).
• Switchboard PCA (page 2-18).
• Display assembly (page 2-23).
• Top case (page 2-26).
• Heat sink (page 2-40).
2-44 Removal and Replacement Service Manual
