Note
When removing the keyboard cover on HP Pavilion 5300 and 5200, HP nx9010, and Compaq
Presario 2500 models, disconnect the speaker cable as indicated in Figure 2-10.
Figure 2-10. Disconnecting the Speaker Cable
Reassembly Note
• Insert the tabs on the left- and right-center of the panel into the mating slots under the keyboard,
and then press the panel into place.
2-14 Removal and Replacement Service Manual
