HP Pavilion ze4200 - Notebook PC

Note
The SDRAM door on HP Pavilion 5300 and 5200, HP nx9010, and Compaq Presario 2500 models
is located in the rear left corner of the notebook bottom, as indicated in Figure 2-4. The procedure
for removing the SDRAM door and modules is the same for all notebook models.
Figure 2-4. Removing an SDRAM Module
HP Pavilion 5300 and 5200, HP nx9010, and Compaq Presario 2500 Models
Reassembly Notes
• Carefully press the SDRAM module into the connector at an angle of about 30°, until it is fully
inserted. Then press down on both sides of the SDRAM module until the latches snap closed.
2-6 Removal and Replacement Service Manual
