Removing Other Components
(Authorized Service Providers Only)
Required Equipment
• #0 and #1 Phillips screwdrivers.
• Small flat-blade screwdriver.
Removal Procedure
1.
2.
Unplug the AC adapter, if present, and remove the battery.
Remove the assemblies and follow the additional steps listed in the table below.
Table 2-5. Removing Components
Component Removal Procedure Additional Steps
Battery, CMOS
Keyboard cover
(page 2-12).
Speaker (page 2-15).
Keyboard (page 2-16).
Switchboard PCA
(page 2-18).
CD/DVD (page 2-20).
Display (page 2-23).
Top case (page 2-26).
Floppy (page 2-32).
Heat sink (page 2-40).
Motherboard (page 2-50).
Reassembly Notes: After replacing the CMOS battery,
set the correct time and date using the BIOS Setup
utility or Date/Time in the Control Panel.
Case, bottom
See page 2-59.
Case, top
See page 2-26.
CD/DVD drive
See page 2-20.
CPU module
See page 2-44.
Display assembly
See page 2-23.
Doors, PCMCIA
Keyboard cover
(page 2-12).
Speaker (page 2-15).
Keyboard (page 2-16).
Switchboard PCA
(page 2-18).
CD/DVD (page 2-20).
Display (page 2-23).
Top case (page 2-26).
Heat sink (page 2-40).
Floppy (page 2-32).
Motherboard (page 2-50).
See page 2-59.
Floppy drive
See page 2-32.
Service Manual Removal and Replacement 2-63
