Removing the Audio PCA
(Authorized Service Providers Only)
Note
The following audio PCA removal instructions apply only to HP Pavilion 5300 and 5200,
HP nx9010, and Compaq Presario 2500 models.
Required Equipment
• #1 Phillips screwdriver.
Removal Procedure
1.
2.
Unplug the AC adapter, if present, and remove the battery.
Remove these additional assemblies:
• Hard disk drive (page 2-9).
• Keyboard cover (page 2-12).
• Keyboard (page 2-16).
• Switchboard PCA (page 2-18).
• Display assembly (page 2-23).
• Top case (page 2-26).
2-38 Removal and Replacement Service Manual
