HP Pavilion ze4200 - Notebook PC User Manual

Component Removal Procedure Additional Steps
Guide, HDD
Keyboard cover
(page 2-12).
Speaker (page 2-15).
Keyboard (page 2-16).
Switchboard PCA
(page 2-18).
CD/DVD (page 2-20).
Display (page 2-23).
Top case (page 2-26).
When replacing the HDD guide, make sure you only
replace the two right screws. Do not replace the two left
screws.
Heat sink (with fan)
See page 2-40.
Keyboard
See page 2-16.
Panel, wireless
Keyboard cover
(page 2-12).
Speaker (page 2-15).
Keyboard (page 2-16).
Switchboard PCA
(page 2-18).
CD/DVD (page 2-20).
Display (page 2-23).
Top case (page 2-26).
Press the tabs on both sides of the panel and then lift it
from the bottom case.
PCA, I/R
See page 2-36.
PCA, left and right
antennas (wireless
models only)
Keyboard cover
(page 2-12).
Speaker (page 2-15).
Keyboard (page 2-16).
Switchboard PCA
(page 2-18).
CD/DVD (page 2-20).
Display (page 2-23).
Top case (page 2-26).
Floppy (page 2-32).
Heat sink (page 2-40).
Motherboard (page 2-50)
Bottom case (page 2-59).
Disconnect the front antenna PCA cables from the
mini-PCI card (page 2-7).
Be careful not to bend the metal tabs on the bottom
case when removing or replacing either of the two
antenna PCAs.
PCA, motherboard
See page 2-50.
PCA, switchboard
See page 2-16.
Socket, PCMCIA
Keyboard cover
(page 2-12).
Keyboard (page 2-16).
CD/DVD (page 2-20).
Display (page 2-23).
Top case (page 2-26).
Floppy (page 2-32).
Heat sink (page 2-40).
Motherboard (page 2-50).
Speaker assembly
See page 2-15.
1. Remove the two screws attaching the socket to the
motherboard.
2. Unplug the PCMCIA socket from the motherboard.
2-64 Removal and Replacement Service Manual
