Note
This section applies only to HP Pavilion 5300 and 5200, HP nx9010, and Compaq Presario 2500
models.
Removal Procedure
1.
2.
Unplug the AC adapter, if present, and remove the battery.
Remove these additional assemblies:
• Hard disk drive (page 2-9).
• Keyboard cover (page 2-12).
• Keyboard (page 2-16).
• Switchboard PCA (page 2-18).
• Display assembly (page 2-23).
• Top case (page 2-26).
• Heat sink (page 2-40).
2-46 Removal and Replacement Service Manual
