Modem
(certain models)
Software-based modem.
Data speed: 56 Kbps (V.92) maximum.
Fax speed: 14.4 Kbps, Class 1 and 2.
Modulation: V.21, V.22, V.22bis, V.23, V.32, V.32bis, V.34, V.90, V.92, X2, Bell 103,
Bell 212A.
Synchronous transfer: V.80.
Compression: V.42bis, MNP5.
Error correction: V.42, MNP2-4.
Fax: Group 3 fax, Class 1. V.17, V.27ter, V.29, V.21.
Wireless LAN
(certain models)
Radio: IEEE 802.11b, WECA Wi-Fi compliant, direct-sequence spread-spectrum.
Operating frequency: 2.5-GHz ISM band, exact frequencies and channels depend on
country.
Raw data rate: 1, 2, 5.5, or 11 Mbps.
Transmitter output: 15 dBm typical (approx. 30 mW), 16 dBm max
(approximately 40 mW).
Receiver sensitivity: –84 dBm typical.
Range: up to 100 m (300 ft) or more, depending on environment and conditions.
On-off button and indicator.
Mini-PCI interface.
Input/Output
9-pin, 115,200-bps serial.
25-pin bi-directional ECP/EPP parallel.
15-pin VGA video-out with DDC support.
S-video TV out (certain models).
PS/2 keyboard/mouse.
4-Mbps IrDA-compliant infrared port (certain models).
IEEE-1394 (certain models).
Universal serial bus (USB 1.1), two ports.
Expandability
One or two 16-/32-bit PC Card slots, Type II or III, CardBus enabled.
Optional port replicator (certain models).
Security Features
User and administrator passwords.
System password.
PC identification displayed at boot.
WMI-accessible electronic serial number.
Kensington MicroSaver lock slot.
Environmental Limits
Operating temperature: 5 to 35° C (41 to 95° F).
Operating humidity: 20 to 90 percent RH (5 to 35° C).
Operating altitude: up to 3000 m (10,000 ft) at 25° C (77° F).
Storage temperature: –20 to 50° C (–4 to 122° F).
Major ICs
CPU: Intel Mobile Pentium 4 processor-M.
Core logic: ALI 1671/1535+ chipset.
Display controller: ATI Mobility Radeon M6-C/P.
Audio/Modem controller: Conexant Smart AMC CX20468-21.
CardBus controller: TI PC1520.
Keyboard/embedded controller: National PC87570.
Super I/O: integrated in core logic.
IEEE 1394: TI TSB43AB22.
LAN: National NS83815.
802.11b wireless LAN: Ambit with Intersil Prism 2.5 chipset.
or
CPU: Intel Mobile Celeron processor.
Core logic: VIA Twister-T + VT8231 chipset.
Display controller: S3 Savage Pro integrated in core logic.
Audio/Modem controller: Conexant Smart AMC CX20468-21.
CardBus controller: O2Micro 6912.
Keyboard/embedded controller: National PC87570.
Super I/O: integrated in core logic.
LAN: VIA Phy, MAC integrated in core logic.
802.11b wireless LAN: Ambit with Intersil Prism 2.5 chipset.
Service Manual Product Information 1-61
