1-1
Introducing the HP Procurve
Switch 2650
1
Introducing the HP Procurve Switch 2650
The HP Procurve Switch 2650 is a multiport switch that can be used to build
high-performance switched workgroup networks. This switch is a store-and-
forward device that offers low latency for high-speed networking.
Throughout this manual, this switch will be abbreviated as the Switch 2650.
The Switch 2650 has 48 auto-sensing 10/100Base-TX RJ-45 ports and two dual-
personality ports—either auto-sensing 10/100/1000Base-T RJ-45 or mini-
GBIC.
This switch is designed to be used primarily as a high-density wiring closet or
desktop switch. With this switch you can directly connect computers, printers,
and servers to provide dedicated bandwidth to those devices, and you can
build a switched network infrastructure by connecting the switch to hubs,
other switches, or routers. In addition, the Switch 2650 offers full network
management capabilities.
This chapter describes your HP Switch 2650 including:
■ Front and back of the switch
■ Switch features
Port
LED
View
Self
Test
Clear
Reset
Fan
Status
4
5
48
47
46
4543
4442
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
Spd mode: off = 10 Mbps, flash = 100 Mbps, on = 1000 Mbps
10/100Base-TX Ports (1 - 48)
Gig-T
Ports
Mini-
GBIC
Ports
1 15 17
16
18
31
32
33
34
47
48
50
49
T
M
T
M
Power
Fault
hp procurve
switch
2650
J4899A
Use only one (T or M) for each Gigabit port
!
1
2
3
Spd
Lnk
Act
FDx
HP Procurve Switch 2650 (HPJ4899A)
