HP ProCurve 2650 Install Guide

2-10
Installing the Switch 2650
Installation Procedures
Installing the Switch 2650
4. Mount the Switch
After you have verified that the switch passes self test, you are ready to mount
the switch in a stable location. The Switch 2650 can be mounted in these ways:
■ in a rack or cabinet
■ on a horizontal surface
■ on a wall
Rack or Cabinet Mounting
The Switch 2650 is designed to be mounted in any EIA-standard 19-inch telco
rack or communication equipment cabinet. Note that the mounting brackets
have multiple mounting holes and can be rotated allowing for a wide variety
of mounting options.
Warning For safe operation, please read the mounting precautions on
page 2-3, before mounting a switch.
Equipment
Cabinet
Note
The 12-24 screws supplied with the switch are the correct threading for
standard EIA/TIA open 19-inch racks. If you are installing the switch in an
equipment cabinet such as a server cabinet, use the clips and screws that came
with the cabinet in place of the 12-24 screws that are supplied with the switch.
Complete step 1, on the next page. Then, plan which four holes you will be
using in the cabinet and install all four clips and partially install the two bottom
screws, as described in step 2 on the following page. Then proceed to step 3.

HP ProCurve 2650 Specifications

General

Switching Capacity	13.6 Gbps
Forwarding Rate	10.1 Mpps
Layer	2
Jumbo Frame Support	Yes
Form Factor	Rack-mountable
VLAN Support	Yes
Layer 3 Routing	No
PoE Support	No
Fanless	No
Altitude	Up to 3, 000 meters
Management	CLI, SNMP
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	15% to 95% non-condensing
