Front bezel
Description Spare part number
Front bezel 745039-001
1. Prepare the computer for disassembly (Preparation for disassembly on page 92).
2. Remove the access panel (
Access panel on page 93).
3. Lift up the three tabs on the side of the bezel (1), then rotate the bezel off the chassis (2).
To install the front bezel, reverse the removal procedure.
94 Chapter 6 Removal and replacement procedures: Small Form Factor
