Bezel blanks
Description Spare part number
Bezel blank 745036-001
On some models, there are bezel blanks covering the 3.5-inch and 5.25-inch drive bays that need to
be removed before installing a drive. To remove a bezel blank:
1. Remove the access panel (
Access panel on page 43)
2. Remove the front bezel (
Front bezel on page 44)
3. Remove the bezel blank for the appropriate drive:
●
To remove a 5.25-inch bezel blank, press inward on the two retaining tabs on the side of the
bezel blank that hold the bezel blank in place (1) and rotate the bezel blank back to remove
it (2).
Bezel blanks
45
